FP10000Q
Sanway
NON
Description :
The FP series switching power amplifiers are Sanway innovative technology achievement. They are designed to achieve unsurpassed sonic performance and longterm reliability for operating even under extreme rigorous conditions. In addition, this workhorse of the high power class TD amplifier is loaded with features including full short circuit open circuit, thermal and mismatched loads protection,and intelligent cooling system etc. Sanway FP10000Q 4 channel live sound amplifier is the core model in the FP series with competitive price, which is a perfect design for large scale events.
Feature :
1. switching power supply
High efficiency and stability of the new switching power supply
2. intelligent signal limiter
Each channel has an independent output signal overload distortion, automatic pressure lImited function,
to avoid DC level because of the audio signal output and burned speakers.
3. multiple detection, multiple protection
A soft start, the second start, the (low) pressure protection, output overload and short circuit protection.
4. high efficiency, low fever
Efficient Class TD amplifier, significantly reduce heat loss.
5. Metal Packaging, high-power transistors, a pure, passionate, authentic audio effects.
6. removable face Network
Removable the hole into the wind-net, easy cleaning.
Applications :
1>. Arenas
2>. Convention Centers
3>. Medium or large Ballrooms
4>. Perfect for corporate
5>. Theaters Music
6>. Club or Church
7>. Concert reinforcement
Specification of switching mode power amplifier FP10000Q:
| ITEM | FP10000Q |
| Output Power | 20-34KHz,1W with 1KHz |
| 8Ω Stereo Power(RMS) | 1350W ×4 |
| 4Ω Stereo Power(RMS) | 2100W ×4 |
| 2Ω Stereo Power(RMS) | 2500W ×4 |
| 8Ω Bridged Power(RMS) | 4200W ×2 |
| 4Ω Bridged Power(RMS) | 5000W ×2 |
| Frequency Response(+0/-0.3dB, 1W/8Ω) | 20Hz -34KHz |
| THD 20Hz-20KHz for 1W | <0.1% |
| Signal-to-Noise Ratio | >112 dBA |
| Channel separation(Crosstalk)at 1KHz | >70 dB |
| Input Connectors (per channel) | 3-pin XLR,electronically balanced |
| Output Connectors (per channel) | Neutrik speakON |
| Class | TD |
| TourClass Protection | short circuit, DC voltage,turn-on/off transient,current inrush |
| Operating voltage | 220V Version: 130-265 V / 110V Version: 65- 135 V selectable |
| Voltage Gain(dB) | 23,26,29,32,35,38,41,44 dB selectable |
| Input impedance | 20 Kohms |
| Level adjustment(per ch.) | Front-panel potentiometer,31position detented from-inf to 0dB |
| Dimensions(WXHXD) | 483×88×396mm |
| Packing dimension | 580×180×560mm |
| Net weight(kg) | 13 |
| Gross weight(kg) | 18 |
FP10000Q 4CH 2 ohms load together:
FAQ:
Q: Does this amp have a built in crossover?
A: No, it doesn't have crossover. If you would like have a crossover fouction, you could choose our DSP-10KQ DSP power amplifier.
Q: Does this run in 2 ohm? Is there a switch in back for 2 ohm?
A: Our FP10000Q could run 2 ohms long term load stably. It does't have a switch in back for 2ohms. Becasue the amp can be load in 2ohms automatically, you could parallel the speakers to be 2ohms or you could use a 2ohms speaker.
Q: Will these FP10000Q amplifiers work well for home theater use or would the fan noise be to much?
A: Yes, the FP10000Q is suitable for home theater use. We will provide quiet noise fan for home theater version power amplifier, so that it can decrease much noise. Please kindly tell us your request before place the order.
Updates: We have HT series for home theater. HT-10Q is same power as FP10000Q
Q: Does this model work with 120V or just 220V?
A: We provide two kinds of voltage version:
220V version power amplifier could run from 135V to 265V
110V version power amplifier could run from 65V to 135V
Please kindly tell us your request before place the order.
