D14
Sanway
Dual 8 inch Line Array
D14 integrated front panel with channel select, volume buttons, input and output LED metering, intuitive navigation buttons, power button and Led indicator.
For convenience, it has 20 factory preset configurations that can be modified and stored in the user presets.
With Powerful intrinsic correction processing, it maximizes the sonic performance of Sanway loudspeakers.
With its two channel full function onboard loudspeaker DSP, with a crossover, parametric EQ filters, limiting and alignment delay, it eliminates the need for outboard loudspeaker processors.
This Flexible Amplifier drives almost any loudspeaker system or configuration by distributing total amplifier power across one, or two channels.
Features
1. Consists of one FP14000 and one 2 in & 2 out digital processor.
2. DSP function: Mute, Polarity, Gain, EQ, Xover, Limiter.
3. Ethernet function (Wi-Fi):to control many D14 amplifiers with one computer
4. Crossover filters: Each output channel can be independently set as LPF and HPF and APF, Butterworth, Bessel, Linkwitz-Riley.
Specification
| MODEL: | D14 | |||
| Input: | 2CH | |||
| Output: | 2CH | |||
| PC Com Port: | 1 USB Com Port on front panel, 1 USB Com Port,2 RS485 Com Port on back panel (RJ-45) | |||
| Processor: | 48KHz Sampling frequency, 48-bit Fixed-Point DSP, 24-bit A/D and D/A converter | |||
| Dynamic range: | >110dB | |||
| Frequency Response: | ±0.25dB, 20Hz --- 20KHz | |||
| Distortion: | < 0.01%, 20Hz - 20KHz @ +10dBu balanced input | |||
| Signal to noise ratio: | >110dB | |||
| crossover filter: | Each output channel can be independently set as LPF and HPF and APF, The parameters can be adjusted, Filter type:Butterworth, Bessel, Linkwitz-Riley; The Crossover Frequency:20Hz---20KHz, Slope:12,18,24 or 48 dB/octave | |||
| EQ: | Bandwidth:0.2 to 36 oct, Frequency:20Hz to 20KHz, Gain: -24dB to +12dB, step:0.2 dB | |||
| Delay: | 0ms to 115ms | |||
| Display: | 2 x 20 LCD | |||
| Store Settings: | 20 user program dynamic storage | |||
| WIFI function ( Ethernet) | Yes | Yes | Yes | |
| DSP AMPLIFIER | ||||
| Model | D14 | |||
| Output Power | ||||
| 8Ω Stereo Power | 2x2350W | |||
| 4Ω Stereo Power | 2x4400W | |||
| 2Ω Stereo Power | 2x7000W | |||
| 8Ω Bridged Monon Power | 1x8700W | |||
| 4Ω Bridged Monon Power | 1x14000W | |||
| Frequenty Response | 20Hz-20kHz ±0.5dB | |||
| THD+N(Rated power,4Ω/KHz)% | 0.10% | |||
| Signal Noise Ration(dB) | 110dB | |||
| Input Impedance | 20KΩ Balanced / 10kΩ Unbalanced | |||
| Output Connectors | Speakon Connectors(NEUTRIK) | |||
| Power Requirement | 100-120V-50-60Hz or 200-240V-50-60Hz | |||
| WIFI function ( INTERNET) | Yes | Yes | Yes | |
| Dimension | ||||
| Airframe | 483×377×88mm | |||
| Weight | ||||
| Weight(net)/(Gross Weight) | 13Kg (Net) / 18Kg (Gross Weight ) | |||
