CA9
Sanway
Overview
The CA series dual-channel amplifiers are ruggedly built from high quality components and feature comprehensive protection circuits to protect your amplifier in the real world. Low-noise design and features applicable to "real world" situations make this unit ideal for audio applications. With outstanding efficiency,outstanding sound quality, extended reliability, it is a perfect match for club, church speakers and theaters music.
Features
• Dual channel progressive cooling system, build in thermostat. Electronic fans cooling the amp from rear to front, avoid overheating.
• Soft-start, over-current, short-circuit, overheating, DC, distortion, voltage limiting protect the amp from the damage of man-made and environment.
• 8 ohms, 4 ohms, 2 ohms load all can be worked for a long time, suit for most regular demand.
• Low harmonic distortion (THD<0.05%), and perfect frequency response (20-20kHz).
• Professional structure design make sure noise is enough low.
• 2U standard chassis, with high strength steel structure.
• Adopting SMT Surface Mounting Technology, ensure good consistency.
• Large efficient transformer, bulk capacitor filtered power, have extremely low distortion in full load, more powerful low-frequency control and more clear sound.
Specification
| Model | CA9 |
| 8 ohm stereo power (RMS) | 650w x 2 |
| 4 ohm stereo power | 1000w x 2 |
| 2 ohm stereo power | 1300w x 2 |
| 8 ohm bridged power | 1900w |
| 4 ohm bridged power | 2800w |
| Frequency response (+o/-0.3dB,1W/8Ω) | 20Hz-20kHz,-3dB@135kHz |
| S/N Rate | ›80dB |
| THD+N (at rated power 1kHz 1W ) | ‹0.05% |
| Damping Factor (at rated power 63Hz) | ›500 |
| Controlled Slew Rate ( 1kHz tone burst 40dB gain) | >-10v/us |
| Input Sensitivity (X40/36dB ) | 0.775v/1.0v/1.4v |
| Class | Class AB |
| Input Connectors | 3 pin-XLR/RCA/TRS |
| Output Connectors | SEPAKON&TOUCH-PROOF BINDING POSTS |
| Amplifier Protection | Dc/Short/Temp/VHF/Limit/Softstar |
| Power Supply | AC 115V/230V,50-60Hz |
| Weight | 24kg |
| Dimension | 2U: 88X482X400mm |
