DA5004
Sanway
Dual 8 inch Line Array
Quick details
1. 4x500W@ 8 ohms , 4x900W@ 4 ohms
2. 4 channel Class D digital audio power amplifier for sales
3. Lightweight portable
Product Advantages
1. Designed for various applications
2. Amazing good sound quality and powerful bass
3. High performance price ratio and reliability
4. Rubberized feet for extra stability
5. Fashionable panel with volume, treble and bass controls for easy adjustment
Specification of 4 channel class d amplifier
ITEM | DA5004 |
8Ω Stereo Power | 4×500W |
4Ω Stereo Power | 4×900W |
8Ω Bridged Power | 2×1600W |
Frequency Response | 20Hz-20KHz ±1dB |
THD+N 1KHz 1W 8Ω | <0.1% |
Signal to Noise Ratio 1KHz | >109dB |
Channel Separation 1KHz | >70dB |
Class | D |
Protection | Short,DCP,OVP,UVP,OCP,OTP |
Operating Voltage | 90V-135V / 180V-265V |
Input Sensitivity | 0.77V |
Input Impedance | 20KΩ |
Dimensions(W×H×D) | 483×88×396mm |
Packing Dimension | 580×180×560mm |
Net Weight(kg) | 9 |
Gross Weight(kg) | 12.5 |
