English  |
| Quantity: | |
|---|---|
CA18
Sanway
Features
-- This CA Series Power Amplifier is H Class circuit.
-- It is a circuit between the digital amplifier and traditional amplifier.
-- And it's designed according to the professional HI-FI(high fidelity) standard.
-- There're two groups of high-power tube installed on both sides, in order to enhance the cooling efficiency.
-- H class circuit is a kind of fast recovery circuit which is equipped with high efficiency intelligent cold system, DC protection, short circuit protection, overheating and overload protection,ect. It can working at 2 Ohms stably for a long time.
-- The amp also makes the sound of speakers to be wide field, structured, thin, clear,uninhibited, glossy, good texture, perfect fitting the high-end speakers.
Overview
CA series is the highend product in 2U 3U traditional transformer. Made by the level two and Class-H amplifier circuit. More perfect on sound and stability than before. Ultra clear high frequency, full at mid, low frequency with a steady flow of motive power make the whole machine to most perfect performance. 2Ω output for long working time are available for many purposes in engineering program. It is really the first choice of indoor recreation projects and lager outdoor performance.
Specification
| Model | CA18 |
| 8 ohm stereo power | 1250w x 2 |
| 4 ohm stereo power | 1725w x 2 |
| 2 ohm stereo power | 2300w x 2 |
| 8 ohm bridged power | 3450w |
| 4 ohm bridged power | 4600w |
| Frequency response (8 ohm) | 20Hz-20kHz,-3dB@135kHz |
| S/N Rate | ›80dB |
| THD+N(8OHM 1KHZ IN 1/4 OUTPUT) | ‹0.05% |
| Damping Factor(8 Ohm 1 K) | ›500 |
| Slew Rate | ›20V/us |
| Input Sensitivity (X40/36dB) | 0.775v/1.0v/1.4v |
| Output topology | 3 Steps Class H |
| Input Connectors | 3 pin-XLR/RCA/TRS |
| Output Connectors | SEPAKON&TOUCH-PROOF BINDING POSTS |
| Power supply | AC 115V/ 230V, 50-60Hz |
| Protection | Dc/Short/Temp/VHF/Limit/Softstar |
| Dimension | 3U: 132x482x400 mm |
| Net Weight | 43kg |
Applications
1>. Arenas
2>. Convention Centers
3>. Medium or large Ballrooms
4>. Perfect for corporate
5>. Theaters Music
6>. Club or Church
7>. Concert reinforcement
Features
-- This CA Series Power Amplifier is H Class circuit.
-- It is a circuit between the digital amplifier and traditional amplifier.
-- And it's designed according to the professional HI-FI(high fidelity) standard.
-- There're two groups of high-power tube installed on both sides, in order to enhance the cooling efficiency.
-- H class circuit is a kind of fast recovery circuit which is equipped with high efficiency intelligent cold system, DC protection, short circuit protection, overheating and overload protection,ect. It can working at 2 Ohms stably for a long time.
-- The amp also makes the sound of speakers to be wide field, structured, thin, clear,uninhibited, glossy, good texture, perfect fitting the high-end speakers.
Overview
CA series is the highend product in 2U 3U traditional transformer. Made by the level two and Class-H amplifier circuit. More perfect on sound and stability than before. Ultra clear high frequency, full at mid, low frequency with a steady flow of motive power make the whole machine to most perfect performance. 2Ω output for long working time are available for many purposes in engineering program. It is really the first choice of indoor recreation projects and lager outdoor performance.
Specification
| Model | CA18 |
| 8 ohm stereo power | 1250w x 2 |
| 4 ohm stereo power | 1725w x 2 |
| 2 ohm stereo power | 2300w x 2 |
| 8 ohm bridged power | 3450w |
| 4 ohm bridged power | 4600w |
| Frequency response (8 ohm) | 20Hz-20kHz,-3dB@135kHz |
| S/N Rate | ›80dB |
| THD+N(8OHM 1KHZ IN 1/4 OUTPUT) | ‹0.05% |
| Damping Factor(8 Ohm 1 K) | ›500 |
| Slew Rate | ›20V/us |
| Input Sensitivity (X40/36dB) | 0.775v/1.0v/1.4v |
| Output topology | 3 Steps Class H |
| Input Connectors | 3 pin-XLR/RCA/TRS |
| Output Connectors | SEPAKON&TOUCH-PROOF BINDING POSTS |
| Power supply | AC 115V/ 230V, 50-60Hz |
| Protection | Dc/Short/Temp/VHF/Limit/Softstar |
| Dimension | 3U: 132x482x400 mm |
| Net Weight | 43kg |
Applications
1>. Arenas
2>. Convention Centers
3>. Medium or large Ballrooms
4>. Perfect for corporate
5>. Theaters Music
6>. Club or Church
7>. Concert reinforcement
