| Fans: | |
|---|---|
| Low Impedance: | |
| Quantity: | |
fp2200
Sanway
20 - 34 khz, 1w with 1 khz
350W x 2
500W x 2
700W x 2
1400W
2200W
580 x 180 x560mm
12kg
fp 2200 Class TD 2 CH Switching Concert Power Amplifier
Description
FP-2200 are 2-channel switching power amplifiers, new generation high quality, high efficiency power amplifiers. Standard 2U height and 12kg light weight make it ideal for touring performance and fixed installations. With full protect functions, it adopts a full range of power output transistors. It supply low distortion, great signal-to-noise ratio, low consumption, high performance, compact size, light weight, delay circuit for soft start and low in rush current advance the appliance to operate efficiently. Two voltage specifications (65V-135V and 135V-265V) are available as per customers requirements.
Features
A. Very high power and channel density
B. Four-channel flexibility
C. Patented Class TD amplifier topology
D. Regulated Switch Mode Power Supply
E . Efficient cooling system
F. Adjustable parameters
G. Comprehensive protection and warning
H. XLR input connectors
I. Heavy-duty binding post or Speakon output connectors
Applications
1. Churches, Museums, Sports venues, Conference centres,
2. Theatres, Auditoria, Shopping malls, Transport terminals,
3. Concert halls, Bars, Restaurants, Lecture theatres
Specifications
| ITEM | fp2200 |
| Output Power | 20-34KHz,1W with 1KHz |
| 8Ω Stereo Power(RMS) | 350W ×2 |
| 4Ω Stereo Power(RMS) | 500W ×2 |
| 2Ω Stereo Power(RMS) | 700W ×2 |
| 8Ω Bridged Power(RMS) | 1400W |
| 4Ω Bridged Power(RMS) | 2200W |
| Frequency Response(+0/-0.3dB, 1W/8Ω) | 20Hz-20KHz ±0.5dB |
| THD+N | 10KHz <0.05% |
| Signal-to-Noise Ratio | <-110dB |
| | 20V/uS |
| Input Connectors (per channel) | Female XLR(PIN+2, Configurable for pin 3+). TRS(tip+) |
| Output Connectors (per channel) | 5-way binging posts or Speakon connectors(market dependent) |
| Class | TD |
| TourClass Protection | turn-on/off transient, current inrush, sub/ultransonic input |
| Voltage Gain(dB) | 20,23,26,29,32,35,38,41, dB selectable |
| Cooling | 4 pcs variable speed DC fans , better than conventional cooling |
| Controls | Front-panel:2 attenuators, power switch, Rear panel, signal ground lift & mode switches |
| Dimensions(WXHXD) | 483×88×396mm |
| Packing dimension | 580×180×560mm |
| Net weight(kg) | 13 |
| Gross weight(kg) | 18 |
