PR380
Sanway
50hz or 60hz(±5%）
overload current protection & shot protection
3 characters LED voltage meter
8 pairs of sequence channels
programable
1%
R≤100mΩ
1PC:10.25/11(kg) 3PCS:33(kg)
Quick details
1 . Biphase /Triphase
2 . 8 channels and 20KW Power supply.
3 . Each channel has of independent EMI-Powe1
Features
● Using Single Chip Micro Computer(MCU) controller. The delay time is programmable & more precise reliably.
● 8 channels and 20KW Power supply. Each channel has of independent EMI-Power Filter , CE certificate approved.
● Using Triphase 5-pin professional socket, Diphase & Triphase are compatible.
● LED voltage meter & LED visual operational interface display the voltage of each line, delay time, power sequence etc .
● With USB lamp
● Every output channel can be turned off immediately in urgent.
● Password function.
● Programming function. Remote control function: the remote control distance is up to 1km.
● Link In & Link Out function .
● Overload Voltage Alarm function: It alarms whenever the voltage is out of the range which you setup.
● Multi-sockets meet your different plugs.
| Model | PR380 |
| Voltage | Biphase:110V or 220V(±20%) Triphase190V or 380V |
| Power Frequency | 50Hz or 60Hz(±5%) |
| Power Input | Biphase&Triphase,5-pin industrial socket, 32A input |
| Protection. | Overload current protection & shot protection |
| Display | 3 characters LED voltage meter 3 characters LED program screen |
| Voltage Meter | 3 characters LED real-time display, ±1% no-load accuracy, ±1% accuracy of full- load |
| Sequencing Channel | 8 pairs of sequence channels of independent control. |
| Power Output | 8 pairs of outputs, connected with audio load,each pair of audio output will not exceed 40A, connected with pure resistance. |
| Time Sequence | Programable |
| Single-way Switch | With Single-way switch, any channel can be tuurgently |
| Voltage setup error | 1% |
| Overload voltage accuracy | ±1% of no load accuracy, ±1% of accuracy of full load |
| Grounding Resistance | R≤100mΩ |
| Dimension(L×W×H) | 1PC:482x400x88/607×183×524(mm) 3PCS:622×599×539(mm) |
| Weight | 1PC:10.25/11(kg) 3PCS:33(kg) |
