LA-208B Dual 15 inch Power Line Array Subwoofer Speaker

1>.Supported with a full range of flying accessories. Proprietary rigging system.
2>.For portable or permanent installation.
3>.Lightweight for easy touring or handling

  • LA-208B

  • Sanway

  • 2 x 15 inch

  • 4 ohms

  • 1000 watts

  • 2000 watts

  • 620mmƗ5500mmƗ750mm

  • 18mm high intensity plywood

  • 55 kg

  • 103 dB SPL

Description

The LA-208 is a small two way line array enclosure designed to bring line array performance benefits to a variety of small and medium scale applications. It meets the need for a versatile, scalable system that can be flown or ground stacked for corporate events, theatres, indoor and outdoor venues. It is also suitable as a delay system for large scale outdoor sound reinforcement.
Following the constant directivity horn design philosophy, The LA-208 combines line array principles with innovative horn loading techniques to produce a next generation, small line array with maximum dynamic impact. Sanway recommends 4pcs LA-208 combination with 1pc LA-208B for extending low frequency.

Applications

1>. Arenas
2>. Convention Centers
3>. Medium or large Ballrooms
4>. Perfect for corporate
5>. Theaters Music
6>. Club or Church
7>. Concert reinforcement

Specifiaction

Frequency Response (±3 dB)  30 Hz - 300Hz
Sensitivity (1w/1m) 103 dB SPL
 Long-term SPL 132dB
Maximum SPL  143 dB
Nominal Impedance 4 ohms
 Power rated(rms) 1000 watts
Peak Power handling 2000 watts
Dimensions (H x W x D) 620mm×5500mm×750mm
 Enclosure Material 18mm high intensity plywood
Surface Finished Textured black paint
Grille Acoustic foam on perforated steel grille
Net weight 55 kg
Low Frequency Driver  2x15" ferrite woofer
