D3-215 1800W+1800W+900W Digital DSP Plate Amplifier with Ethernet

1. consists of class D amplifier board, switching power supply, DSP and Ethernet module
2. It is 1800W+1800W+900W at 4 ohms 3 channels module
3. compact installation dimension with powerful output

Quantity:
  • D3-215
  • Sanway



Key Feature

1>. D3-215 powered speaker module consists of class D amplifier board; switching power supply and DSP and Ethernet module.
2>. It is 1800W+1800W+900W at 4 ohms 3 channels module
3>. This module is mounted an agile DSP module for versatile PA Systems Performance, you could manage this PA system via PC which connected with a USB, RS-485 or internet cable.
4>. Compact installation dimension with powerful output
5>. D3-215 is perfect for three way line array speaker or one touring sound reinforcement system consists of one subwoofer and two bi-amped top speaker.



Specification



ITEMD3-215
 8Ω  PowerL:1500W + M:1500W + H:500W
 4Ω  PowerL:1800W + M:1800W + H:900W
Frequency Response20Hz-20KHz ±1dB
THD+N 1KHz 1W 8Ω<0.1%
Signal to Noise Ratio  1KHz>100dB
Channel Separation  1KHz>80dB
ClassD
ProtectionShort,DCP,OVP,UVP,OCP,OTP
Operating Voltage110V Version:90V-135V / 220V Version 180V-265V
Input Sensitivity1V
Input Impedance20KΩ
DSP FuctionMUTE,Polarity,Gain,Delay,
Limiter,Mixer,EQ,XOver
DSP ControlUSB,RS-485,NET
Dimensions(W×H×D)550x160x130mm
Packing Dimension640x260x225mm
Net Weight(kg)7.9
Gross Weight(kg)10


D3-215 connectorD3-215 plate amplifier

DSP software


D3 software
