VERA36 double 10 inch three way Line Array Speaker

1. High efficienty Neodymium Drivers
2. Smooth frequency and phase response
3. High-strength birch plywood enclosure
4. Compact size and light weight

Quantity:
  • VERA36
  • Sanway


Description

The central element of VERA36 is the mid-range horn, driven by two 8" cone speakers, with the mid-high frequency unit comprising two 1.4" compression drivers and a newly developed waveformer, positioned coaxially in the centre. The vertical dispersion is 10 degree, while 80 and 120 degree versions are available for the horizontal dispersion. The low-mid range is supplemented by two 10" long excursion bass speakers. It is remarkable that below 400 Hz all four cone speakers work together providing impressive reserves of low-mid and punch.All this means that VR36 can compete with much bigger 2 × 12" systems, sometimes even more.

Features

1. High efficienty Neodymium Drivers
2. Smooth frequency and phase response
3. High-strength birch plywood enclosure
4. Compact size and light weight

Specification

Model VERA36
Drivers 2 x 10" LF / 2 x 8" MF / 2 x 1.4" HF
Frequency range 60 - 16000 Hz
Power capacity programm / peak:
1000 / 2000 W     LF
800 / 1600 W       MHF
Impedance 8 Ohms LF    8 Ohms MHF
Coverage range (h x v)         80 ° x 10° oder 120° × 10
Sensitivity 1 W / 1 m 98 dB LF    110 dB MHF
SPLmax / 1 m / peak         141 dB
Dimensions (h x w x d)         310 x 700 x 580 mm
Weight        41.6 kg


VERA36 dimension

Demo of Vera 36 line array and S33 subwoofer


Project case of Vera 36 dual 10 inch line array for outdoor live show

Sanway VERA 36 line array and KS28 subwoofer provided a wonderful performance to 38th Annual Belize Day





10 inch woofer of Vera 36 3 Way Line Array

Vera 36 10 inch woofer 10NW650-16.pdf

8 inch midrange driver of Vera 36 3 way line array speaker

Vera36 8inch MF driver 8NMP52-16.pdf

3 inch HF driver of Vera 36 line array

Vera 36 3 inch HF driver DE800-8.pdf
