FCS966
Sanway
Description
Sanway FCS966 Dual 30 Band Graphic Equalizer uses the Constant Q topology, Each eq fader has +/-15dB of adjustable gain, all the inputs and outputs are electronically balanced, with optional transformer balancing. Also, with separate LF and HF contour filters which can change an overall sound balance without disturbing a detailed room or loudspeaker response.
Specification
| Item | FCS966 |
| Input Impedance | 10kOhm, electronically balanced |
| Output Impedance | < 50kOhms, electronically balanced |
| Input/Output | XLR-type, 1/4" TRS jack and Phoenix/Combicon screw terminals |
| CMRR | >-40dB@1KHz |
| Maximum Input Level | >+20dBu |
| Maximum Output Level | >+20dBu into 600 Ohms |
| GAIN control | +10dB to - infinity |
| HP filter control | OUT to 250Hz @ 12dB/octave |
| LF contour | +/-6dB shelving @ 50Hz 6dB/octave |
| HF contour | +/-6dB shelving @ 14kHz 6db/octave |
| FREQUENCY bands | +/-15dB on ISO centres with a Q of 4 |
| Frequency Response | 5Hz to 45kHz +/-1dB |
| Noise | <-94dB 22Hz to 22kHz |
| Dynamic Range | > 115dB |
| Cross Talk | >-80dB @1kHz |
| Distortion | <0.005%THD (80kHz measurement BW) 20Hz-20kHz |
| Dimensions | 19" x 5.25" x 7.1" (483mm x 134mm x 180mm) |
| Weight | 6.6lbs (3kgs), unpacked |
| AC Power | 115/230V AC, 50/60Hz, 30VA |
